| Bearing Cap Diameter |
1-15/16 in |
| Bearing Diameter (in.) (C) |
1.378 |
| Bearing Diameter (Max) |
1.3784 |
| Bearing Diameter (Min) |
1.3779 |
| Center Line to End of Hub |
6-1/8 in |
| For Use With |
Outward sliding joint |
| Hub Diameter |
2-5/8 in |
| Includes Slinger/Plug |
Yes |
| Involute |
Yes |
| Involute Spline |
No |
| Length Thru Hole (Q) |
2.25 |
| Material |
Steel |
| Outside Yoke Dimension (in.) (E) |
6.094 |
| Series |
1710 |
| Shoulder Length (in.) (G) |
1.125 |
| Spline Diameter |
1-31/32 in |
| Spline End To Brg Shoulder (Y) |
7.469 |
| Spline End To Weld (in.) (K) |
8.812 |
| Type |
Splined Hole Yoke |
| Yoke Style |
BP |
| Yoke Type |
Full Round |
