1.5 POINTS
1710 FLANGE YOKE
#SPI6-2-769
Specifications
| Bearing Cap Diameter | 1-15/16 in |
| Center Line to End of Hub | 8-7/16 in |
| C/L To C/L | 1.914 |
| Flange Face to Centerline | 2 in |
| Flange Or Swing Dia. (in.) (A) | 8 |
| Joint Angle | 8 deg |
| Material | Steel |
| Outside Yoke Dimension (in.) (E) | 6.094 |
| Series | 1710 |
| Type | Flanged Yoke |
| Weight (lbs) | 0.32 |
Interchanges & Equivalent parts:
| 2104-62769 |
| 38MU357 |
| 6-2-629 |
| 6-2-859 |
| 62629 |
| 62769 |
| 62769-SP |
| 877758 |
| D62769 |
| E62769 |
| SP 6 2 769 |
| SP 62769 |
| 6-2-769 |
