Air Filters L: 16,66 in, OD: 8,66 in, ID: 7,06 in
#DONP114931
Product Overview
Why Choose Donaldson Safety Filters?
Features & Benefits
- Safety filters have two functions: to act as a backup to the primary filter and to protect the engine during primary filter servicing
- Serve as a backup filter in case of primary filter damage or improper installation
- Prevent contaminants from entering the clean side of the air intake system during primary filter servicing
- Designed to plug rapidly if contamination finds its way past the primary filter, alerting operators about an issue
- Recommend that safety filters are replaced with every third primary filter change unless there has been a failure of the primary filter
Specifications
| Application | DONALDSON STG16 |
| Diameter Range | 8 to 8.99 in |
| Efficiency (Percent) | 0.999 |
| Efficiency Test Std | ISO 5011 |
| Family | STG |
| Inner Diameter | 7.06 in (179.4 mm) |
| Length | 16.66 in (423.2 mm) |
| Outer Diameter | 8.66 in (219.96 mm) |
| Overall Length | 17.04 in (432.9 mm) |
| Length Range | 16 to 16.99 in |
| Style | Round |
| Type | Safety Air Filter |
Interchanges & Equivalent parts:
| AR080 |
| ARM109159 |
| 121795 |
| PA1905 |
| CFM436 |
| 87132 |
| AF9159 |
| LAF9159 |
| P822733 |
| 139 |
| 14246 |
| 6112 |
| 10039 |
| 9575 |
| A46947 |
| AA2900 |
| AF883 |
| AF883M |
| AF943 |
| FA109159 |
| FA9159 |
| AAR82900 |
| AFR8883 |
| AFR8883M |
| AFR8943 |
| CA536SY |
| CA7462SY |
| GA357 |
| GA357M |
| AF241 |
| A0083 |
| A9159 |
| HDA0083 |
| HDA9159 |
| E744LS |
| SA10833 |
| KC210013 |
| LA436 |
| A738 |
| A447C |
| C22281 |
| CF22269 |
| FA196 |
| 2132 |
| 109159 |
| 70073N |
| 70806N |
| 84645S |
| AP536SY |
| A62207 |
| AF2207 |
| FA196Q |
| HDA5337 |
| A7915 |
| SL8843 |
| SFA0883S |
| 2799600 |
| U09159 |
| 42132 |
| 542132 |
| 800176884 |
| 71409553 |
| 72527839 |
| MD534 |
| 2X3309 |
| AE27030 |
| 427 |
| 93132 |
| AP3029A |
| HF154 |
| 3014051322 |
| 45928 |
| 2650616408 |
| 2914500700 |
| 362760 |
| 5536276000 |
| 277426 |
| 1849115 |
| E2116 |
| 5730118 |
| 401476203 |
| 86033527 |
| 86034041 |
| 61329601 |
| 6N6072 |
| 151849115 |
| 20850539 |
| 224636 |
| 423217C1 |
| 547159R2 |
| 850550 |
| 942625C1 |
| KWH0050 |
| M1950526 |
| N1950526 |
| S224636 |
| SFD45253 |
| Z0850539 |
| 1N8164 |
| 3I0088 |
| 3I0225 |
| 427202 |
| 4N9164 |
| 8C2238 |
| 1314432H91 |
| 69PS4670 |
| 1514580S |
| 1541435 |
| 1562432 |
| 156432 |
| 1564832 |
| 1564837 |
| M1564832 |
| 1514580 |
| E1514580 |
| MA575 |
| 4002720002 |
| AA34006 |
| WA2265 |
| MX151693 |
| 4031215 |
| 2NTL8 |
| KWH0030 |
| S3450A |
| CA6814 |
| 450617 |
