Air Filters L: 9,81 in, OD: 12,78 in, ID: 10,14 in
#DONP523048
Features & Benefits
- Safety filters have two functions: to act as a backup to the primary filter and to protect the engine during primary filter servicing
- Serve as a backup filter in case of primary filter damage or improper installation
- Prevent contaminants from entering the clean side of the air intake system during primary filter servicing
- Designed to plug rapidly if contamination finds its way past the primary filter, alerting operators about an issue
- Recommend that safety filters are replaced with every third primary filter change unless there has been a failure of the primary filter
Specifications
| Application | CATERPILLAR 8N2556 |
| Diameter Range | 12 to 12.99 in |
| Efficiency Test Std | ISO 5011 |
| Inner Diameter | 10.14 in (257.6 mm) |
| Length | 9.81 in (249.2 mm) |
| Outer Diameter | 12.78 in (324.62 mm) |
| Length Range | 9 to 9.99 in |
| Style | Round |
| Type | Safety Air Filter |
Interchanges & Equivalent parts:
| P523048 |
| 6815 |
| 46815 |
| ARM523048 |
| PA2848 |
| PA3933 |
| 88815 |
| P143022 |
| AF4874 |
| AF4874Q |
| AFR84874 |
| CA7490SY |
| SA16135 |
| LA1839 |
| LAF3048 |
| 70870N |
| SL8971 |
| 546815 |
| 94815 |
| 8N2556 |
| FC2154 |
| 22058 |
| 687916 |
| AF523048 |
| WGA1074 |
| 022058 |
| 1131579 |
| 2191-P523048 |
| 8N-2556 |
| AF4874FLG |
| ARM52-3048 |
| DONP523048 |
| FIL6815 |
| LAF3048LFB |
| ABP N03 A23048 |
| DN P523048 |
| DN P523048 |
| 2NTT5 |
