Air Filtration System L: 11,77 in, OD: 5,99 in
#DOND100032
Product Overview
Donaldson branded filters are designed specifically to give you effective, consistent performance over the life of your engine. The company that invented air filters for heavy-duty engines delivers the broadest vehicle and equipment coverage, the most consistent quality and the best overall performance.
Specifications
| Diameter Range | 5 to 5.99 in |
| Family | PSD |
| Length | 11.77 in (299 mm) |
| Media Brand | PowerCore® |
| Outlet Diameter | 6 in (152.4 mm) |
| Overall Length | 20.83 in (529.1 mm) |
| Rated Flow High Range | 706 cfm (20 m³/min) |
| Rated Flow Low Range | 541 cfm (15,3 m³/min) |
| Rated Flow Mid Range | 628,61 cfm (17,8 m³/min) |
| Restriction HR | 10 in H2O (254 mm H2O) |
| Restriction LR | 6,01 in H2O (152,4 mm H2O) |
| Restriction MR | 8,01 in H2O (203,2 mm H2O) |
| Length Range | 11 to 11.99 in |
Interchanges & Equivalent parts:
| D100032 |
| 2191-D100032 |
| DN D100032 |
| 64589617 |
| DOND100032 |
