Air Filtration System L: 13,89 in, OD: 7 in
#DONG150049
Features & Benefits
- RadialSeal Sealing Technology ensures reliability, is easy to service and makes the filter self centering, self-aligning and self-sealing
- Durable plastic housing corrosion free and lightweight
- Superior performance in thousands of on- and off-road applications.
Specifications
| Diameter | 14.62 in (371.4 mm) |
| Diameter Range | 13 to 13.99 in |
| Family | EPG |
| Inlet Diameter | 7.01 in |
| Length | 13.89 in |
| Outlet Diameter | 7 in |
| Overall Length | 17.52 in |
| Rated Flow High Range | 822 cfm (23.3 m³/min) |
| Rated Flow Low Range | 28252 cfm (801 m³/min) |
| Rated Flow Mid Range | 748.67 cfm (21.2 m³/min) |
| Restriction HR | 10 in H2O (254 mm H2O) |
| Restriction LR | 5.99 in H2O (152 mm H2O) |
| Restriction MR | 8 in H2O (203 mm H2O) |
| Length Range | 13 to 13.99 in |
| Style | Radialseal |
Interchanges & Equivalent parts:
| G150049 |
| A2200003001 |
| BN2296141 |
| NG150049 |
| DNG150049 |
| DONG150049 |
| QJ0203001 |
| 2296141 |
| DN G150049 |
| DN G150049 |
| AF2120 |
| AF2356 |
