Air Filtration System L: 5,43 in, OD: 1,75 in, ID: 1,75 in
#DONG042544
Sommaire du produit
Why Choose Donaldson?
Caractéristiques et avantages
- RadialSeal Sealing Technology ensures reliability, is easy to service and makes the filter self centering, self-aligning and self-sealing
- Durable plastic housing corrosion free and lightweight
- Superior performance in thousands of on- and off-road applications.
Spécifications
| Diameter | 4.8 in (122 mm) |
| Diameter Range | 1 to 1.99 in |
| Family | FPG |
| Inner Diameter | 1.75 in (44.5 mm) |
| Length | 5.43 in (138 mm) |
| Outer Diameter | 1.75 in (44.45 mm) |
| Overall Length | 11.48 in (291.6 mm) |
| Rated Flow High Range | 70 cfm (2 m³/min) |
| Rated Flow Low Range | 57 cfm (1.6 m³/min) |
| Rated Flow Mid Range | 63.57 cfm (1.8 m³/min) |
| Restriction HR | 10 in H2O (254 mm H2O) |
| Restriction LR | 5.99 in H2O (152 mm H2O) |
| Restriction MR | 8 in H2O (203 mm H2O) |
| Length Range | 5 to 5.99 in |
| Style | Radialseal |
Interchanges et pièces équivalentes:
| HSG3078 |
| 1G65711010 |
| MA383AC |
| 300918 |
| 825117 |
| 825117X |
| 892679 |
| 1951157 |
| 62316 |
| 955805 |
| 955808 |
| 70048215 |
| 391127 |
| 892676 |
| 1001118280 |
| 110101690 |
| 110101757 |
| M19801 |
| 1E32442G01 |
| 5088 |
| 11928712500 |
| DN G042544 |
| DN G042544 |
| AH19081 |
| 187431 |
| 02250139234 |
| 2191-G042544 |
| AF2308 |
| AF2399 |
| DONG042544 |
| 2250139234 |
