Système de filtration d'air H: 8,27 po, DE: 4 po,
#DOND090073
Sommaire du produit
Donaldson branded filters are designed specifically to give you effective, consistent performance over the life of your engine. The company that invented air filters for heavy-duty engines delivers the broadest vehicle and equipment coverage, the most consistent quality and the best overall performance.
Spécifications
| Diameter Range | 4 to 4.99 in |
| Family | PSD |
| Length | 8.27 in (210.1 mm) |
| Media Brand | PowerCore® |
| Outlet Diameter | 4 in (101.6 mm) |
| Overall Length | 17.05 in (433.1 mm) |
| Rated Flow High Range | 381 cfm (10,8 m³/min) |
| Rated Flow Low Range | 290 cfm (9 m³/min) |
| Rated Flow Mid Range | 340 cfm (9,63 m³/min) |
| Restriction HR | 10 in H2O (254 mm H2O) |
| Restriction LR | 6,01 in H2O (152,4 mm H2O) |
| RM de restriction | 8,01 in H2O (203,2 mm H2O) |
| Plage de longueur | 8 to 8.99 in |
Interchanges et pièces équivalentes:
| D090073 |
| 1001102845 |
| 104185P |
| 12890220 |
| 15046853 |
| 6511563M91 |
| 909599 |
| DOND090019 |
