| Air Spring Type |
1T Reversible Sleeve |
| Application |
Granning 2577 |
| Bottom Mount |
Flat |
| Bottom Plate Diameter |
10-1/4 in (26.04 cm) |
| Bottom Plate Hole/Stud Qty |
4 |
| Compressed Length |
6-45/64 in (17.02 cm) |
| Diameter |
10-1/8 in (25.73 cm) |
| Extended Length |
20-3/4 in (52.71 cm) |
| Firestone Bellows Number |
1T15M-6 |
| Loading Capacity at 20 psig |
1420 lb-ft |
| Loading Capacity at 60 psig |
4260 lb-ft |
| Loading Capacity at 90 psig |
6390 lb-ft |
| Material |
Natural Rubber |
| Piston Height |
5-43/64 in (14.4 cm) |
| Piston Number |
9951 |
| Piston Width (in.) |
10-1/4 in (26.04 cm) |
| Temperature |
57°C @ -54°C (134.6°F @ -65.2°F) |
| Top Mount |
Stud |
| Top Plate Diameter |
9 in (22.86 cm) |
| Top Plate Hole/Stud Qty |
2 |
| Top Plate Number |
3235 |
| Weight |
15.9 lb (7.21 kg) |
