Air Spring Mounting Kit, For INTRAAX, CONNEX, VANTRAAX HKANT 40K and 46K, HKAT 50K, HKAL 46K and HKARL 46K
#TURS-22631/2
Product Overview
Air Spring Mounting Kit, Fits Axle Type: 5 in Axle and Large-Diameter Axle, 15/18/19 in Ride Height, For Top-Mount Suspension System, Fits Models: INTRAAX, CONNEX, VANTRAAX HKANT 40K and 46K, HKAT 50K, HKAL 46K and HKARL 46K, Includes Spiralock Nuts, Pipe Plug, Air Fitting and Flange Nut
Features & Benefits
- Standard dual combo stud
- Use with S-22510-2 air spring spacer only
- Limited jounce
- With 2 in weld-on air spring pedestal - When model includes a 2 in weld-on pedestal under the air spring
- With cast air spring pedestal - when model includes a cast, bolt-on pedestal under the air spring
- Drum brakes, air disc brakes
Specifications
| Includes | Spiralock Nuts, Pipe Plug, Air Fitting and Flange Nut |
| Quantity | 2 |
| Application | Top-Mount Suspension System |
| Fits Axle Type | 5 in Axle and Large-Diameter Axle |
| Fits Models | INTRAAX, CONNEX, VANTRAAX HKANT 40K and 46K, HKAT 50K, HKAL 46K and HKARL 46K |
| Ride Height | 15; 18; 19 in |
| Product Category | Air Spring Mounting Kit |
Interchanges & Equivalent parts:
| TURS22631/2 |
| 334-1630 |
| HENS226312 |
| S22631/2 |
| S226312 |
| TURS226312 |
| S-22631/2 |
