Air Spring, Rolling Lobe Air Spring, Aluminum Base, 8900 lb at 100 psi, 7000 lb at 80 psi, 9 in Compressed Length, 22 in Extended Length, 13.7 in
#MZHAB1D28G-9144
Product Overview
Air Spring, Rolling Lobe Air Spring, Aluminum Base, 8900 lb at 100 psi, 7000 lb at 80 psi, 9 in Compressed Length, 22 in Extended Length, 13.7 in, For SAF Holland/Neway
Features & Benefits
- Bumper
- Bottom plate C to C diameter (D): 7.87 in
- Bottom plate diameter (C): 10.25
- Bottom plate hole/stud qty: 4
- Top plate C to C diameter (B): 5.5
- Top plate diameter (A): 11.31
- Top plate hole/stud qty: 2
- Aluminum bottom plate type
- 13.5 in design height
- 70 cpm natural frequency, bellows#: 6365, 566-28-3-021 Goodyear, 1T19F-7, 1T19L-7 Firestone, 1D28G Automann
Specifications
| Air Spring Type | Rolling Lobe |
| Application | SAF Holland/Neway |
| Bottom Plate Hole/Stud Qty | 4 |
| Bumper | Yes |
| Compressed Length | 9 in |
| Design Height (in.) | 13-1/2 in (34.29 cm) |
| Diameter | 11-5/16 in (28.73 cm) |
| Extended Length | 22 in |
| Material | Aluminum Base |
| UPC | 889626208874 |
| Weight | 22.79 lb |
| Capacity | 8900 lb at 100 psi, 7000 lb at 80 psi |
| Fitting Size | 13.7 in |
| Manufacturer Part Number | AB1D28G-9144 |
| Product Category | Air Spring |
Interchanges & Equivalent parts:
| AB1D28G-9144 |
