Air Spring, Rolling Lobe Air Spring, Steel Base, 4.9 in Compressed Length, 16.5 in Extended Length, For Reyco Granning, Rowe
#MZHAB1DK10B-5423
Product Overview
Air Spring, Rolling Lobe Air Spring, Steel Base, 4.9 in Compressed Length, 16.5 in Extended Length, For Reyco Granning, Rowe
Features & Benefits
- Bumper
- Bottom plate C to C diameter (D): 2.25 in
- Bottom plate diameter (C): 7.24
- Bottom plate hole/stud qty: 3
- Top plate C to C diameter (B): 3.38
- Top plate diameter (A): 6.31
- Top plate hole/stud qty: 2
- Steel bottom plate type
- 1 in design height
- 78 cpm natural frequency, bellows#: 6 6.5-13 Contitech, 1DK10B Automann
Specifications
| Air Spring Type | Rolling Lobe |
| Application | Reyco Granning, Rowe |
| Bottom Plate Hole/Stud Qty | 3 |
| Bumper | Yes |
| Compressed Length | 4.9 in |
| Contitech Bellow # | 6 6.5-13 |
| Design Height (in.) | 10 in (25.4 cm) |
| Diameter | 6-5/16 in (16.03 cm) |
| Extended Length | 16.5 in |
| Material | Steel |
| UPC | 889626209239 |
| Weight | 10.65 lb |
| Manufacturer Part Number | AB1DK10B-5423 |
| Product Category | Air Spring |
Interchanges & Equivalent parts:
| AB1DK10B-5423 |
