ASA, Spline: 1-1/2 in - 10, L: 5-1/2 in
#ROCA143275H1152
Specifications
| Angle | 34 deg |
| Arm Length # 1 | 5-1/2 in |
| Automatic or Manual | Automatic |
| Brake Surface Diameter | 16-1/2 in |
| Bushing I.D. | 1/2 in |
| Chamber Sizes | 20 in |
| Clevis Type | Unclevised |
| Maximum Torque | More than 45 in pounds |
| Model | Meritor |
| Notes | Red piston. Drum Brake. |
| Number of Splines | 10 |
| Spline Diameter | 1-1/2 in |
| Spline Diameter-Spline Count | 1-1/2 in - 10 |
| Type | Stroke-Sensing |
Interchanges & Equivalent parts:
| 8235-A143275H1152 |
| TDA A14 3275H1152 |
| TDAA143275H1152 |
