ASA, Spline: 1-1/2 in - 28, L: 5-1/2 in
#ROCA53275M1183
Features & Benefits
- Enhances overall vehicle safety
- Ensures precise brake adjustment
- Increases brake system efficiency
- Features corrosion-resistant coating
- Provides reliable braking performance
- Minimizes brake system maintenance needs
- Meets industry standards and specifications
- Offers durability for extended service life
Specifications
| Angle | 29 deg |
| Arm Length # 1 | 5-1/2 in |
| Chamber Sizes | 20 in |
| Clevis Type | Unclevised |
| Maximum Torque | More than 45 in pounds |
| Model | Meritor |
| Notes | Yellow piston. Drum Brake. |
| Number of Splines | 28 |
| Spline Diameter | 1-1/2 in |
| Spline Diameter-Spline Count | 1-1/2 in - 28 |
| Type | Stroke-Sensing |
| VMRS Code | 013-017-005 |
| Height | 3-3/32 in |
| Width | 6-3/64 in |
| Quantity | 1 |
| Weight | 2.82 lbs |
Interchanges & Equivalent parts:
| 8235-A53275M1183 |
| ATIA53275M1183 |
| TDA A5 3275M1183 |
| TDAA53275M1183 |
| A53275M1183 |
| 3275M1183 |
