ASA, Spline: 1-1/2 in - 28, L: 5-1/2 in
#ROCA773275H1152
Features & Benefits
- Enhances braking system longevity
- Ensures consistent braking efficiency and safety
- Controls brake shoe travel for optimal performance
- Automates brake adjustment to save time and effort
- Prevents excessive brake wear due to unadjusted shoes
- Adjusts brake automatically to maintain proper clearance
- Regulates brake system effectively for smooth operations
- Maintains optimal clearance between brake drums and shoes
Specifications
| Arm Length # 1 | 5-1/2 in |
| Bushing I.D. | 1/2 in (1.27 cm) |
| Chamber Sizes | 20 in (50.8 cm) |
| Clevis Type | Unclevised |
| Maximum Torque | More than 45 inch pounds |
| Model | Meritor |
| Notes | Yellow piston. Drum brake. |
| Number of Splines | 28 |
| Spline Diameter | 1-1/2 in (3.81 cm) |
| Spline Diameter-Spline Count | 1-1/2 in - 28 |
| Type | Stroke-Sensing |
Interchanges & Equivalent parts:
| 20422027 |
| 8235-A773275H1152 |
| TDAA773275H1152 |
