ASA, Spline: 1-1/4 in - 10, L: 5-1/2 in
#ROCA13275M1183
Features & Benefits
- Enhances overall vehicle safety
- Ensures precise brake adjustment
- Increases brake system efficiency
- Features corrosion-resistant coating
- Provides reliable braking performance
- Minimizes brake system maintenance needs
- Meets industry standards and specifications
- Offers durability for extended service life
Specifications
| Arm Length # 1 | 5-1/2 in |
| Automatic or Manual | Automatic |
| Bushing I.D. | 1/2 in (1.27 cm) |
| Chamber Sizes | 16 in (40.64 cm) |
| Clevis Type | Unclevised |
| Maximum Torque | More than 45 inch pounds |
| Model | Meritor |
| Notes | Red piston. Drum Brake. |
| Number of Splines | 10 |
| Spline Diameter | 1-1/4 in (3.18 cm) |
| Spline Diameter-Spline Count | 1-1/4 in - 10 |
| Type | Stroke-Sensing |
Interchanges & Equivalent parts:
| 8235-A13275M1183 |
| ATIA13275M1183 |
| TDA A1 3275M1183 |
| TDAA13275M1183 |
