Automann Air Spring, Rolling Lobe Air Spring, 8 Compressed Length, 23.1 Extended Length, 12.6, For Hendrickson Mack
#MZH566.ER9656
Features & Benefits
- Automann Bellows #: 1DK23M
- Bottom Plate Dia. (C): 10, Bottom Plate C to C Dia. (D): BS08660, Bumper: Yes, Bracket: AB9372P
- Bottom plate hole/stud qty: 1
- Bottom plate type: plastic
- Contitech bellows#: 9 10-18.5
- Firestone bellows#: 1T15M8
- Top Plate C to C Dia. (B): 6.2
- Top plate dia. (a): 9
- Top plate hole/stud qty: 2
- Triangle bellows #: 6391
Specifications
| Air Spring Type | Rolling Lobe |
| Application | Hendrickson Mack |
| Bottom Mount | Stud |
| Cap Number | 7018, NBD-10218 |
| Compressed Length | 8 |
| Diameter | 2.875 in |
| Extended Length | 23.1 |
| Piston Height | 1.484375 in |
| Piston Number | 6908, NBD-16510 |
| Quantity | 1 |
| Top Mount | Flat |
| UPC | 889626738289 |
| Weight | 15.8 lb |
| Fitting Size | 12.6 |
| Manufacturer Part Number | 566.ER9656 |
| Product Category | Air Spring |
