Battery Cable, SGR Type, 4/0 Gauge, 50 Ft Spool, Red, 100% Copper, 60V Rated
#GRO82-6716
Product Overview
Our Type SGR Bulk Battery Cable is stranded with 100% copper conductor and jacketed in chlorinated polyethylene (CPE). It meets all SAE J1127 specifications and is rated at 60 volts. The cable features a diameter of 0.726 inches with 361 strands, providing excellent conductivity and durability.Battery Cable, SGR, Red Insulation, Copper Conductor, EPDM Insulation, 4/0 GA Conductor, 0.726 in Dia, SAE J1127 Standards, 361 Strands, -40 to 105 °C Temperature Rating, 60 V, 50 ft Length
Features & Benefits
- Rated @ 60V
- 100% Copper Cable
- All Battery Cable is spooled
- Meets all SAE code J1127 specifications
- General Purpose Ground Rubber jacket rated at -40°C (-40°F) to 90°C (194°F)
- Manufactured to Meet or Exceed O.E.M. Specifications in Function, Form & Fit.
- 1,000 Foot Custom Sized Spools Also Available by Special Order.
- We Also Offer a Full Line of Lugs, Terminals, Solder Slugs, Heat Shrink, Cutters, Crimpers, and Tie Straps to Custom Make Battery Cables at Your Service Facility.
Specifications
| Application | Battery Cable |
| Length | 50 ft |
| Type | Battery Cables - Type SGR |
| UPC | 621935028046 |
| Conductor Size | 4/0 Gauge |
| Conductor Material | Copper |
| Diameter | 0.726 in |
| Insulation Color | Red |
| Insulation Material | Chlorinated Polyethylene (CPE) |
| Number of Conductors | 1 |
| Standards | SAE J1127 |
| Strands | 361 |
| Temperature Rating | -40°C (-40°F) to 90°C (194°F) |
| Voltage Rating | 60 V |
| Product Category | Battery Cable |
Interchanges & Equivalent parts:
| 826716 |
| 7376-826716 |
| 82-6716GR0 |
| GRO 82 6716 |
| GRO826716 |
| ZBJ826716 |
| ZBJD826716 |
| 826716FT |
| 82-6716 |
| P52481 |
| 04932 |
