Brake Camshaft, Splines: 1-1/2 in - 10
#ROC2210M2483
Features & Benefits
- For slight variations in length. extra spacer washers may be required.
- Q Plus?Ö cams can be used to replace the standard Q style cams; however. a Q style cam cannot be used to replace a Q Plus?Ö cam.
Specifications
| Brake Type | Meritor Q |
| Bushing Journal Length (in.) | 2-1/4 in (5.72 cm) |
| Camshaft Length | 20-7/16 in (51.92 cm) |
| OE Mfg. | Meritor |
| Right or Left Side | Right |
| Spline Diameter | 1-1/2 in (3.81 cm) |
| Spline Diameter-Spline Count | 1-1/2 in - 10 |
| Splines | 10 |
| Length Range | 20 to 20.99 in |
Interchanges & Equivalent parts:
| 04-572041 |
| 16391 |
| 17-580 |
| 202100-205-RH |
| 202100-205R |
| 202100-Y3-205R |
| 219317 |
| 2210-E-5413 |
| 2210-F-3594 |
| 2210M2483-RI |
| 41422008 |
| 580444 |
| 65381 |
| 2210-M-2483C |
| 4571841 |
| 4572041 |
| 7-5-64 |
| 7-5-64R |
| 700-17-236 |
| 72411 |
| 72412 |
| 761035011 |
| 8235-2210M2483 |
| 974401R1 |
| ATI2210M2483 |
| C424R |
| CS1424A |
| CS41507 |
| E-1424A |
| E1424 |
| E1424RH |
| E556 |
| GD562R |
| GD565R |
| H565R |
| KBP5594 |
| L173 |
| M-562R |
| M-565R |
| M16WK102-17 |
| M16WK103-17 |
| M16WK110-5 |
| M16WK1105 |
| M16WKR10203 |
| M562R |
| M662R |
| NL1319 |
| SIRC424R |
| TDA 2210M2483 |
| TDA2210M2483 |
| TP1164 |
| TP507 |
| WA05-5000 |
| ZZCS41507 |
