Brake Camshaft, Splines: 1-1/2 in - 28
#ROC2210L7604
Features & Benefits
- Ensures optimal brake shoe movement
- LH designation for easy identification
- Ensures smooth operation during braking
- Left-hand orientation ensures proper fit
- Precision-engineered for reliable braking
- Designed to withstand high braking forces
- Enhances overall braking system efficiency
- Durable material for long-lasting performance
Specifications
| Brake Surface Diameter | 16-1/2 in (41.91 cm) |
| Brake Type | Meritor Q Plus |
| Bushing Journal Length (in.) | 1-49/64 in (4.49 cm) |
| Camshaft Length | 13-29/64 in (34.18 cm) |
| Height | 3-11/32 in (8.5 cm) |
| OE Mfg. | Meritor |
| Right or Left Side | Left |
| Spline Diameter | 1-1/2 in (3.81 cm) |
| Spline Diameter-Spline Count | 1-1/2 in - 28 |
| Splines | 28 |
| Length Range | 13 to 13.99 in |
| VMRS Code | 013-017-004 |
| Weight | 4.06 lbs (8.95 kg) |
| Width | 4-21/32 in (11.83 cm) |
Interchanges & Equivalent parts:
| 04-481342 |
| 04481342 |
| 12548511 |
| 1693473C1 |
| 18-531 |
| 18-823 |
| 2210-G-7001 |
| 2210-H-5442 |
| 2210H5442S |
| 2210L7604-RI |
| 2210N5396 |
| 4461352 |
| 4481342 |
| 8235-2210L7604 |
| ATI2210L7604 |
| CS40188 |
| CS41770 |
| CS9673AL |
| E-4733A |
| E-9673 |
| E4733 |
| G15513517 |
| HQ-10318L |
| HQ10318L |
| L-2887 |
| L-3103 |
| L-3105 |
| MER2210L7604 |
| RW2210L7604 |
| TDA 2210L7604 |
| TDA2210L7604 |
