Brake Drum, 16-1/2 in x 5 in, 10 holes, (78 lb)
#ROC53123815002
Features & Benefits
- Lightweight design generates 15%+ weight savings compared to standard cast drums
- Lighter. stronger design features one-piece outer shell with a fused cast iron brake liner
- Exceeds FMVSS-121 dynamometer specifications
- Designed. cast. and machined for optimal balance and performance
- Backed by a nationwide warranty and the best product support in the business
- Balance within practice per TMC RP608
- Webb Wheel Products is your OE first-fit and aftermarket heavy-duty wheel-end component parts leader
- Manufactured in IATF 16949 or ISO 9001 registered facilities
Specifications
| Axle Capacity (lb) | 50707 kg (23000 lbs) |
| Back Plate Thickness | 1/4 in (0.64 cm) |
| Bolt Circle Diameter | 11-1/4 in (28.58 cm) |
| Bolt Hole (Number) | 10 |
| Brake Shoe Width | 5 in (12.7 cm) |
| Brake Size | 16-1/2 in x 5 in |
| Brake Surface Diameter | 16-1/2 in (41.91 cm) |
| Brake Surface Width | 5-13/16 in (14.77 cm) |
| Bridge Width | 5 in (12,7 cm) |
| Drum Mounting | Outboard |
| Height | 12 in (30.48 cm) |
| Hole Size | 1-1/4 in (3.18 cm) |
| Maximum Diameter | 16-5/8 in (42.23 cm) |
| Overall Depth | 9-7/32 in (23.42 cm) |
| Pilot Diameter | 8-25/32 in (22.31 cm) |
| Type | Steel Shell |
| VMRS Code | 013-017-006 |
| Weight | 76 to 80 lbs |
| Weight (lbs) | 35.39 kg (78 lb) |
| Wheel Type | Disc |
| Width | 5 in (12.7 cm) |
Interchanges & Equivalent parts:
| 95151B |
| TDA 53 123815 002 |
| TWD 3123815002 |
