Brake Drum, 16-1/2 in x 7-1/2 in, 10 Holes, BDA Type, Outboard Mount, 107 lb
#GUN3796X
Product Overview
This 16.5 in x 7.5 in brake drum is designed for heavy-duty truck axles. It features 10 bolt holes, outboard mounting, and durable cast construction for reliable braking performance. Engineered to meet or exceed OEM specifications, it offers a high level of quality suitable for every truck and trailer manufacturer.Brake Drum, BDA Brake, Outboard Mount, Disc Wheel, 11-1/4 in Bolt Circle Dia, 1 in Bolt Hole Dia, 16-1/2 x 7 in Brake, 16-1/2 in Brake Surface Dia, 7.5 in Brake Surface Width, 10 Holes, 8-25/32 in Pilot Dia, 10.12 in Height
Features & Benefits
- All Gunite Brake Drums & Disc Brake Rotors Are Fully Protected by One of the Industrys Most Comprehensive Warranties on Material and Workmanship.
- Manufactured to Meet or Exceed O.E.M. Specifications in Function. Form & Fit.
- Gunite Brake Drums & Disc Brake Rotors Are Available Nationwide Through Over 400 Independent Warehouse Distributors. and Various O.E.M. Dealer Networks.
- Gunite Brake Drums & Rotors Offer a Level of Engineering Quality That Meets or Surpasses the Requirements of Every Truck & Trailer Manufacturer.
- Gunite Offers the Industry's Most Complete Line of Brake Drums & Disc Brake Rotors.
Specifications
| Back Plate Thickness | 1/2 in |
| Bolt Circle Diameter | 11-1/4 in |
| Brake Size | 16-1/2 in x 7-1/2 in |
| Brake Surface Diameter | 16-1/2 in |
| Brake Surface Width | 7-1/2 in |
| Depth | 10-3/16 in |
| Flange Thickness | 1/2 in |
| Height | 10.12 in |
| Packaging | Individual / Bulk |
| Pilot Diameter | 8-25/32 in |
| Type | BDA |
| VMRS Code | 013-017-006 |
| Weight | 106 to 110 lbs |
| Weight (lbs) | 49.11 kg (107 lb) |
| Wheel Type | Disc |
| Width | 7 in |
| Bolt Hole Diameter | 1 in |
| Brake Type | BDA |
| Mount Type | Outboard |
| Number of Holes | 10 |
| Product Category | Brake Drum |
Interchanges & Equivalent parts:
| 20536276 |
| 3796X-GJ |
| GUN 3796X |
| GUN3796X |
| ZBR3796X |
| 78503B |
| 66826F |
| 10041055 |
