Brake Drum, 16-1/2 in x 7 in, 10 holes, (94 lb)
#ROC53123564002
Features & Benefits
- Lightweight design generates 15%+ weight savings compared to standard cast drums
- Lighter. stronger design features one-piece outer shell with a fused cast iron brake liner
- Exceeds FMVSS-121 dynamometer specifications
- Designed. cast. and machined for optimal balance and performance
- Backed by a nationwide warranty and the best product support in the business
- Balance within practice per TMC RP608
- Webb Wheel Products is your OE first-fit and aftermarket heavy-duty wheel-end component parts leader
- Manufactured in IATF 16949 or ISO 9001 registered facilities
Specifications
| Axle Capacity (lb) | 23,000 |
| Bolt Circle Diameter (in.) | 11.25 |
| Bolt Hole Diameter (in.) | 0.81 |
| Brake Diameter (in.) | 16.5 |
| Brake Size | 16.50 x 7.00 |
| Brake Surface Width | 7.86 in. |
| Brake Width (in) | 7 |
| Drum Mount | Outboard |
| Finished Weight | 93.70 lb |
| Marketing Group | Brake Drums - X30 |
| Number of Bolt Holes | 10 |
| Overall Depths (in.) | 10.38 |
| Pallet Quantity | 16 |
| Pilot Diameter | 8.53 in. |
| Type | X30 MTB |
| Unit Pack | 1 |
| UPC | 737238990291 |
| VMRS Code | 013-017-006 |
| Wheel Type | Disc |
Interchanges & Equivalent parts:
3098925, 35763564, 53-123564, 53-123564-002, 53123564, 53123564002-RI, 67101B, 8235-53123564002, 8HA433, 96893B, ATI53123564002, DW123564, GUN 3166X, GUN 9021X, HWI 87101B, MER53-123564-002, MOT87101B, RW53-123564-002, STE87101B, TDA 53 123564 002, TDA53123564002, 3166GUN, GUN 3166, 123564, STE87101B, 96893B, 53-123564-002, HWI 87101B, 53123564002-RI, DW123564, GUN 3166X, GUN 9021X, MOT87101B, MER53-123564-002, RW53-123564-002, 67101B, TDA 53 123564 002, 8HA433, 53123564, 8235-53123564002, ATI53123564002, TDA53123564002, 35763564, 53-123564, 3098925, GUN 3166, 3166GUN, 123564
