| Application |
Meritor EX225 |
| Bolt Circle Diameter |
9-13/16 in (24.92 cm) |
| Diameter |
17-1/4 in (43.82 cm) |
| Diameter Range |
17 to 17.99 in |
| Discard Thickness (in.) |
1-5/8 in (4.13 cm) |
| Flange Thickness |
1-1/8 in (2,86 cm) |
| Hauteur |
12 in (30.48 cm) |
| Taille de l'orifice |
5/8 in (1.59 cm) |
| Longueur |
19-1/2 in (49.53 cm) |
| Modèle |
EX225 |
| Nouvelle épaisseur de disque |
1-3/4 in (4.45 cm) |
| Remarques |
Casting 23-123547; Tone ring mount holes; 8,24 Bolt Circle 1/4 -20 UNC |
| Nombre de trous de boulon |
10 |
| Profondeur totale |
5-19/32 in (14.21 cm) |
| Diamètre du pilote |
7-5/8 in (19.38 cm) |
| Profondeur du rotor |
5-9/16 in (14.12 cm) |
| Type |
U-Shaped |
| CUP |
737238877103 |
| Code VMRS |
013-017-001 |
| Poids |
83.85 lb (38.03 kg) |
