CUP
#TIM29620
Specifications
| Cup Backface Backing Diameter (Db) | 3.98 in (101.09 mm) |
| Cup Backface ""To Clear"" Radius (r) | 0.130 in (3.30 mm) |
| Cup Frontface Backing Diameter (Da) | 4.33 in (109.00 mm) |
| Cup Outer Diameter (D) | 4.4375 in (112.713 mm) |
| Cup Width (C) | 0.7500 in (19.050 mm) |
| Design Units | Imperial |
| Geometry Factor (Cg) | 0.117 |
| ISO Factor (e) | 0.49 |
| ISO Factor (Y) | 1.23 |
| Series | 29600 |
