Donaldson Muffler, 9 in Diameter, 20 in Length, 4 in Inlet Diameter
#DONM090594
Product Overview
Muffler, Low Range: 10 dBA, High Range: 15 dBA Attenuation, Back Pressure Rating: Low Range: 0.98 InHg, Mid Range: 2.01 InHg, High Range: 2.99 InHg, 9.02 in Body Dia, 4.02 in Inlet Dia, 1
Features & Benefits
- Donaldson delivers a full line of aftermarket liquid, lube, air, hydraulic, and exhaust system components.
- Products and technology designed to consistently meet required specifications – and your expectations.
- Superior performance in thousands of on- and off-road applications.
Specifications
| Body Diameter | 9.02 in |
| Color | Aluminized |
| Height | 9 in |
| Inlet Diameter | 4 in |
| Inlet Quantity | 1 |
| Length | 20 in |
| Material | Steel |
| Outlet Diameter | Pipe Connection |
| Outlet Quantity | 1 |
| Reversible | No |
| Shape | Round |
| Style | 1 |
| Width | 9 in |
| Attenuation | Low Range: 10 dBA, High Range: 15 dBA |
| Back Pressure Rating | Low Range: 0.98 InHg, Mid Range: 2.01 InHg, High Range: 2.99 InHg |
| Body Shape | Round |
| Mounting Type | Pipe Connection |
| Product Category | Muffler |
Interchanges & Equivalent parts:
| 3888 |
| 87400594 |
| 87400594Q |
| 86560M |
| SM4490 |
| 90910 |
| 91910 |
| XD414 |
| 1909316 |
| AU103151 |
| 131204 |
| NM090594 |
| 1243122H1 |
| 4013311000 |
| 3114112501 |
| 413311 |
| DCM090594 |
| 1432461H1 |
| B253311 |
| 348027 |
| 9575M090594 |
| 322622 |
| 1511657 |
| DNM090594 |
| 124312241 |
| 86983714 |
| 7642000093 |
| 31252 |
| HD414 |
| 140760801 |
| M14958 |
| 2191M090594 |
| 29323061 |
| 18421 |
| 70930 |
| D137637 |
| 22572 |
| 02250186513 |
| 004013311000 |
| 01804116 |
| 1282347 |
| 2191-M090594 |
| 2250186513 |
| 31252HDM |
| 7-0045 |
| DONM090594 |
| HD-414 |
| HD-414HDM |
| NFM86560M |
| 1243 122 H1 |
| DN M090594 |
| DN M090594 |
| FG 86560M |
| 22571 |
