Fairview Hydraulic Steel ISO A Coupler, 1 in Female Pipe, 3000 psi, Interchangeable with Parker 6600 Series
#FAIQD-ISOAC16-16F
Product Overview
Fairview's ISO A interchange coupler is compatible with Parker 6600 series, Aeroquip 5600 series, Safeway S56 series, and other manufacturers' couplers and nipples built to I.S.O. 7241-1 series “A” standards. Designed for hydraulic applications requiring quick connection and disconnection, it is suitable for trucks, trailers, snow plows, agricultural, dump, and construction equipment.Coupler, ISO A Interchange, Coupler x Female Pipe, Maximum Operating Pressure: 3000 psi, 1 in Nominal, -40 To 250 °F
Features & Benefits
- 4 to 1 safety factor
- High strength steel construction
- Interchangeable with Parker 6600 series, Aeroquip 5600 series, Safeway S56 series and other manufacturer’s couplers and nipples built in accordance with I.S.O. 7241-1 series “A”
- 1 Coupler x 1 Female Pipe, 3000 psi
- Hydraulic applications where connection and disconnection is required either for maintenance or operation, for use on truck and trailer, snow plows, agricultural, dump, construction equipment
- Temperature range: -40 °F to 250 °F
- Proven ball lock mechanism
Specifications
| Material | Steel |
| Standards | I.S.O. 7241-1 series “A” |
| Type | ISO A Coupler |
| Application | Hydraulic; Trucks; Trailers; Snow Plows; Agricultural; Dump; Construction Equipment |
| Connection Type | Coupler x Female Pipe |
| Maximum Operating Pressure | 3000 psi |
| Nominal Size | 1 in |
| Temperature Range | -40°F to 250°F (-40°C to 121.1°C) |
| Manufacturer Part Number | QD-ISOAC16-16F |
| Product Category | Coupler |
Interchanges & Equivalent parts:
| QD61C1616F |
| U34QDISOAC1616F |
| U34QD61C1616F |
| 8KF8 |
| 66011616 |
| ANV-1-NPT-F |
| S565-8 |
| QD-ISOAC16-16F |
| 103951403 |
| 11334 |
| 2F539 |
| 51335K55 |
| 56-800 |
| 61C16-16F |
| 6601-16-16 |
| A10010N |
| ANV-1-F |
| ANV1NPTF |
| B-6601-16-16 |
| C201-16-16 |
| C401-16 |
| CA5608-36 |
| G95621-1616 |
| HA1541100 |
| NS565-8 |
| QD-ISOAC16-16FPX5 |
