FILT ASSY 25 MICR 25PSI BYP
#BUYHFA22525
Product Overview
The hfa2 series 50 gpm return line filter assembly from buyers productsblocks contaminants as small as 10 microns from returning to your hydraulic reservoir. This filter head is rated up to 50 GPM for return line flow and can take up to 150 PSI of working pressure, with your choice of a 15 or 25 PSI bypass. It has four gauge ports. The assembly comes with the filter head and either a 10 or 25 micron filter element. Items can also be purchased separately.
Features & Benefits
- The HFA2 Series 50 GPM Return Line Filter Assembly from Buyers Products blocks contaminants as small as 10 microns from returning to your hydraulic reservoir. This filter head is rated up to 50 GPM for return line flow and can take up to 150 PSI of working pressure, with your choice of a 15 or 25 PSI bypass. It has four gauge ports. The assembly comes with the filter head and either a 10 or 25 micron filter element. Items can also be purchased separately.
- Filters contaminants down to 10 or 25 microns from the oil returning to the reservoir.
- Extends the life of your hydraulic system.
Specifications
| Filter Media | Cellulose |
| Filter Rating | 25µm |
| In Tank/Out Of Tank | External |
| Maximum Flow Return | 50 GPM |
| Maximum Flow Suction | 15 GPM |
| Maximum Pressure | 150 psi (10.34 bar) |
| Minimum Operating Temperature (Deg F) | -22°F (-30°C) |
| Number Of Elements | 1 |
