Firestone Air Spring 1T Reversible Sleeve, 4.3 in Compressed Length, 14.82 in Extended Length

#FIRW01-358-8738

Product Overview


Although air springs are produced in single, double, and triple convoluted and reversible sleeve styles, only those manufactured by Firestone Industrial Products Company bear the trademark “Airide™.” Airide springs were pioneered and perfected by Firestone, and only Firestone offers a complete line of Airide springs, with replacement springs available for virtually every vehicular air suspension system. Today, Airide springs are used by practically all manufacturers who offer air suspension on their vehicles. While it may appear simple, an air spring is actually a highly sophisticated and complex product. Even slight changes in design, methods of construction, or materials used can make vast and significant differences in performance. It makes good sense to specify Airide springs by Firestone. That trade name on an air spring guarantees you the benefit of the very latest technical developments and improvements. It is your assurance of a product not only engineered and perfected to perform, but which also has a long history of superior performance in actual use.Air Spring, 1T Reversible Sleeve Air Spring, 4.3 in Compressed Length, 14.82 in Extended Length, 10.62 in Width

See More
See Less

Specifications


Air Spring Type 1T Reversible Sleeve
Application Holland (Neway) 90557271 (NSH225, NSB225, RLU250)
Bottom Mount Stud
Bottom Plate Diameter 9-9/16 in
Bottom Plate Hole/Stud Qty 5
Compressed Length 4.3 in
Diameter 10-5/8 in
Extended Length 14.82 in
Firestone Bellows Number 1T17C-3
Piston Height 2-61/64 in
Piston Number 9528
Piston Width (in.) 9-9/16 in
Top Mount Stud
Top Plate Diameter 10-3/8 in
Top Plate Hole/Stud Qty 2
Top Plate Number 3301
Weight 12.8 lb (5.8 kg)
Width 10.62 in
Product Category Air Spring

Interchanges & Equivalent parts:


352-8738
3040-W013588738
FI W01 358 8738
FSIW013588738
TWDW013588738
W01-358-8738
90557271
See more
