Firestone Air Spring 1T Reversible Sleeve, 7.4 in Compressed Length, 22-1/2 in Extended Length

#FIRW01-358-9923

Product Overview


Although air springs are produced in single, double, and triple convoluted and reversible sleeve styles, only those manufactured by Firestone Industrial Products Company bear the trademark “Airide™.” Airide springs were pioneered and perfected by Firestone, and only Firestone offers a complete line of Airide springs, with replacement springs available for virtually every vehicular air suspension system. Today, Airide springs are used by practically all manufacturers who offer air suspension on their vehicles. While it may appear simple, an air spring is actually a highly sophisticated and complex product. Even slight changes in design, methods of construction, or materials used can make vast and significant differences in performance. It makes good sense to specify Airide springs by Firestone. That trade name on an air spring guarantees you the benefit of the very latest technical developments and improvements. It is your assurance of a product not only engineered and perfected to perform, but which also has a long history of superior performance in actual use.Air Spring, 1T Reversible Sleeve Air Spring, 7.4 in Compressed Length, 22-1/2 in Extended Length, 10.12 in Width

See More
See Less

Specifications


Air Spring Type 1T Reversible Sleeve
Application Holland (Neway) 90557118 (AR92 & 93-15&16)
Bellows 1T15M-7.5
Bottom Mount Stud
Bottom Plate Diameter 10-1/4 in
Bottom Plate Hole/Stud Qty 1
Compressed Length 7.4 in
Diameter 10-1/8 in
Extended Length 22-1/2 in
Material Natural Rubber
Piston Height 5-43/64 in
Temperature 57°C @ -54°C (134.6°F @ -65.2°F)
Top Mount Stud
Top Plate Diameter 9 in
Top Plate Hole/Stud Qty 2
Weight 13.7 lb (6.21 kg)
Width 10.12 in
Capacity 6480 lb-ft
Product Category Air Spring

Interchanges & Equivalent parts:


1R12-481
1R12481
352-9923
90557118
9923
FIR9923
1R12-533
8429
9 10-17.5 P 429
905-57-118
AS9923
FI W01 358 9923
FS9923
FSIW013589923
G2299923200
GTK-358-9923
TR9923
TWDW013589923
W013589923
1R12533
64278
W01-358-9923
AR-93-15
AR-93-16
