Firestone Air Spring 1T Reversible Sleeve, 7.4 in Compressed Length, 25.8 in Extended Length, Model 1T17B-11

#FIRW01-358-8746

Product Overview


Although air springs are produced in single, double, and triple convoluted and reversible sleeve styles, only those manufactured by Firestone Industrial Products Company bear the trademark “Airide™.” Airide springs were pioneered and perfected by Firestone, and only Firestone offers a complete line of Airide springs, with replacement springs available for virtually every vehicular air suspension system. Today, Airide springs are used by practically all manufacturers who offer air suspension on their vehicles. While it may appear simple, an air spring is actually a highly sophisticated and complex product. Even slight changes in design, methods of construction, or materials used can make vast and significant differences in performance. It makes good sense to specify Airide springs by Firestone. That trade name on an air spring guarantees you the benefit of the very latest technical developments and improvements. It is your assurance of a product not only engineered and perfected to perform, but which also has a long history of superior performance in actual use.Air Spring, 1T Reversible Sleeve Air Spring, 7.4 in Compressed Length, 25.8 in Extended Length, 10.12 in Width

See More
See Less

Features & Benefits


  • Manufactured to Meet or Exceed O.E.M. Specifications in Function, Form & Fit.
  • Today, Airide Springs are Used by Practically All Manufacturers Who Offer Air Ride Suspensions on Their Vehicles.
  • Airide Springs Were Pioneered & Perfected by Firestone, and Only Firestone Offers a Complete Line of Airide Springs.

Specifications


Air Inlet 1/4 in NPT
Air Spring Type 1T Reversible Sleeve
Application Holland (Neway) 90557235
Bead Plate (Top) & Deflated Bellows O.D. 10.38 in @ 10.12 in
Bottom Plate Diameter 10-1/4 in
Bottom Stud Configuration 1/2 in-13 UNC
Compressed Length 7-13/32 in
Diameter 10-1/8 in
Extended Length 25-51/64 in
Firestone Bellows Number 1T17B-11
Piston Height 5-19/32 in
Piston Number 9532
Piston Width (in.) 10-1/4 in
Top Bead Plate Hardware Key 2 x Threaded Hole 3/8-16 in Blind Nut on Bead Plates 1/2-13 in Pistons
Top Plate Diameter 10-3/8 in
Top Plate Number 3335
Weight 15.7 lb (7.12 kg)
Width 10.12 in
Product Category Air Spring

Interchanges & Equivalent parts:


1R13-208
352-8746
8746
90557235
FIR8746
10 10-21 P 774
1R13208
AS8746
AS87460
FI W01 358 8746
FS8746
FSIW013588746
G2298746200
TWDW013588746
W01-675-8746
W013588746
64728
W016758746
W01-358-8746
RLU-250
