Firestone Air Spring 1T Reversible Sleeve, 9.2 in Compressed Length, 24.3 in Extended Length

#FIRW01-358-9922

Product Overview


Although air springs are produced in single, double and triple convoluted and reversible sleeve styles, only those manufactured by Firestone Industrial Products Company bear the trademark “Airide™.” Airide springs were pioneered and perfected by Firestone, and only Firestone offers a complete line of Airide springs, with replacement springs available for virtually every vehicular air suspension system. Today, Airide springs are used by practically all manufacturers who offer air suspension on their vehicles. While it may appear simple, an air spring is actually a highly sophisticated and complex product. Even slight changes in design, methods of construction, or materials used can make vast and significant differences in performance. It makes good sense to specify Airide springs by Firestone. That trade name on an air spring guarantees you the benefit of the very latest technical developments and improvements. It is your assurance of a product not only engineered and perfected to perform, but which also has a long history of superior performance in actual use.Air Spring, 1T Reversible Sleeve Air Spring, 9.2 in Compressed Length, 24.3 in Extended Length, 10.12 in Width

See More
See Less

Specifications


Air Spring Type 1T Reversible Sleeve
Application Holland (Neway) 90557119 (AR92-17) (AR93-17)
Bellows 1T15M-7.5
Bottom Mount Stud
Bottom Plate Diameter 10-1/4 in
Bottom Plate Hole/Stud Qty 1
Compressed Length 9.2 in
Diameter 10-1/8 in
Extended Length 24.3 in
Loading Capacity at 90 psig 6480 lb-ft
Material Natural Rubber
Piston Height 7-9/16 in
Temperature 57°C @ -54°C (134.6°F @ -65.2°F)
Top Mount Stud
Top Plate Diameter 9 in
Top Plate Hole/Stud Qty 2
Weight 15 lb (6.8 kg)
Width 10.12 in
Capacity 6480 lb-ft
Product Category Air Spring

Interchanges & Equivalent parts:


1R12-498
1R12911
352-9922
90557119
1R12-911
1R12498
9 10-17.5 P428
AS9922
FI W01 358 9922
FS9922
FSIW013589922
G2299922200
HOL90557119
REA1R12-498
TWDW013589922
W013589922
9 10-17.5 P 428
W01-358-9922
AR-93-17
