Goodyear
GOODYEAR AIR SPRING
#ARB1R12-401
Features & Benefits
- Superior Rubber Chemistry
- Reduced Weight
- Internal Wall Cord
- Comfort
- Firestone W01-358-9371, ContiTech 9 10-18.5 P 521, Fleetride 1R12-1062, International 1670043C1, International 1686386C1
Specifications
| Bead Plate (Top) Mounting Bolts Dimension Center to Center | 5-45/64 in (14.48 cm) |
| Bellows | Goodwill 566243038 |
| Bottom Plate Alignment | 45 deg |
| Bottom Plate Diameter | 10-15/64 in (25.98 cm) |
| Bottom Plate Hole Stud Qty | 2 |
| Bracket | Yes |
| Bumper | No |
| Compressed Length | 6-45/64 in (17.02 cm) |
| Goodyear Bellow # | 566243038 |
| Height | 12 in (30.48 cm) |
| Length | 16 in (40.64 cm) |
| Maximum Height | 20 in (50.8 cm) |
| Plate Type | Composite |
| Quantity | 1 |
| Top Plate Diameter | 9 in (22.86 cm) |
| Top Plate Hole Count | 4 |
| Type | Rolling Lobe Air Springs |
| Weight | 16 lb (7.26 kg) |
| Width | 13 in (33.02 cm) |
