Grote Battery Cable, Type SGR, 4/0 Gauge Copper Conductor, 25 ft, Red Insulation, Rated 60V
#GRO82-6743-UNIT
Product Overview
Made from 100% copper cable, this Grote Type SGR battery cable meets all SAE J1127 specifications and is rated for 60 volts. It features a durable EPDM insulation with a red jacket, designed for general purpose grounding and rated for temperatures from -40°C (-40°F) up to 105°C (221°F). The cable is spooled for easy handling and installation.Battery Cable, SGR, Copper Conductor, Insulation Material: EPDM, Red Insulation, 4/0 GA Conductor, 0.726 in Dia, 25 ft L, Standards: SAE J1127, 361 Strands, Temperature Rating: -40 to 105 °C, 60 V
Features & Benefits
- Rated @ 60V
- 100% Copper Cable
- All Battery Cable is spooled
- Meets all SAE code J1127 specifications
- General Purpose Ground Rubber jacket rated at -40°C (-40°F) to 90°C (194°F)
- EPDM Insulation for enhanced durability
- Diameter: 0.726 in
- 361 Strands for flexibility and conductivity
Specifications
| Application | General Purpose Grounding |
| Length | 25 ft |
| Quantity | 1 |
| Type | Battery Cables - Type SGR |
| Conductor Size | 4/0 GA |
| Conductor Material | Copper |
| Diameter | 0.726 in |
| Insulation Color | Red |
| Insulation Material | EPDM |
| Number of Conductors | 1 |
| Standards | SAE J1127 |
| Strands | 361 |
| Temperature Rating | -40 to 105 °C |
| Voltage Rating | 60 V |
| Product Category | Battery Cable |
