Haldex ILAS III Fully Automatic Lift Axle Control Valve - Air Suspension Valve for Heavy Duty Trucks and Trailers
#MID90555426
Product Overview
Haldex develops and manufactures brake systems for heavy trucks, trailers, and buses. The product offering covers all primary components and subsystems included in complete air brake systems. The ILAS III is a fully automatic lift axle control valve designed for precise operation in commercial vehicles and trailers, enhancing suspension performance and axle control.Lift Axle Control Valve, Fully Automatic, NPT Inlet, NPT Outlet, 1/4-18 Inlet, 1/4-18 Outlet, 20 psi, 62 psi Drop Pressure, For Commercial Vehicles and Trailers
Features & Benefits
- Replaces 90555288
- Integrated Lift Axle System; Responds to Pressure in Air Suspension and Automatically Lowers the Lift Axle When Loaded.
- Automatically Lifts Axle When Load is Removed.
- One Component Reduces Assembly Time And Complicated Plumbing.
- Solid Structure Allows for Easy and External Mounting.
- ILAS® III provides precise operation of lift axles for commercial vehicles and trailers.
- Error-proof valve lowers lift axle when unit is loaded.
- Integrated mounting holes and solid structure allow for easy installation.
- ILAS® III replaces many lift axle systems which typically require multiple components and fittings.
Specifications
| Application | Commercial Vehicles and Trailers |
| Outlet Size | 1/4-18 |
| Type | ILAS III Fully Automatic Lift Axle Control Valve |
| Includes | Integrated mounting holes |
| Inlet Size | 1/4-18 |
| Inlet Type | NPT |
| Outlet Type | NPT |
| Pressure Rating | 20 psi, 62 psi Drop |
| Product Category | Lift Axle Control Valve |
Interchanges & Equivalent parts:
| 90555426 |
| MID90555288 |
| HAL90555426 |
| 352072000 |
| 90555288 |
| 90555346 |
