Hydraulic, Cartridge L: 18,78 in, OD: 3,78 in, ID: 1,99 in
#DONP567040
Features & Benefits
- Donaldson offers the industry’s largest selection of hydraulic, lube and gear oil filtration products for contamination control.
- Donaldson hydraulic filters and accessories reduce a broad range of contaminants, providing superior performance in thousands of applications.
- Products and technology designed to consistently meet required specifications - and your expectations.
Specifications
| Diameter Range | 3 to 3.99 in |
| Efficiency Beta 1000 | 25 Micron |
| Efficiency Beta 1000 (Micron) | 23 Micron |
| Inner Diameter | 1.99 in (50.6 mm) |
| Length | 18-25/32 in (47.7 cm) |
| Outer Diameter | 3-25/32 in (9.6 cm) |
| Overall Length | 18.64 in (473.5 mm) |
| Length Range | 18 to 18.99 in |
| Style | Cartridge |
Interchanges & Equivalent parts:
| HP455L1825MB |
| P567040 |
| PT23070MPG |
| LH7040 |
| DTRFIL2225UM |
| RF2AH1825A |
| HF29104 |
| R5111G25 |
| 93317Q |
| 933117Q |
| 933119Q |
| SBF100218Z25B |
| SBF100218Z25V |
| 1107477 |
| HC2252FDT19H |
| HC2252FDT19Z |
| HC2252FKT19H |
| HC2252FKT19Z |
| HC2252FUT19H |
| HC2252FUT19Z |
| HC2252FCT19H |
| HC2252FCT19Z |
| 64132198 |
| 932474 |
| HC2252FRT19Z |
| HC2252FHT19H |
| SBF1002-18Z25B |
| SBF1002-18Z25V |
| HC2252FHT19Z |
