Hydraulic Filter, Spin-On L: 10,67 in, Thread : 1 1/2-16 UN , OD: 5,08 in
#DONP169077
Product Overview
Why Choose Donaldson?
Features & Benefits
- Donaldson offers the industry’s largest selection of hydraulic, lube and gear oil filtration products for contamination control.
- Donaldson hydraulic filters and accessories reduce a broad range of contaminants, providing superior performance in thousands of applications.
- Products and technology designed to consistently meet required specifications - and your expectations.
Specifications
| Diameter Range | 5 to 5.99 in |
| Efficiency Beta 1000 | 11 Micron |
| Gasket ID | 4.73 in (120.2 mm) |
| Gasket OD | 5.04 in (128.1 mm) |
| Length | 10-43/64 in (27.1 cm) |
| Outer Diameter | 5-5/64 in (12.9 cm) |
| Length Range | 10 to 10.99 in |
| Thread Size | 1 1/2-16 UN |
| Vehicle Make | Case/Case IH |
Interchanges & Equivalent parts:
| BT731 |
| BT731KIT |
| BT8308MPGKIT |
| HF28929 |
| SH56763 |
| SPH9409 |
| 1329214C1 |
| 3I0742 |
| 20633 |
| HF169077 |
| 020633 |
| 3I-0742 |
| BT731 KIT |
| DN P169077 |
| DN P169077 |
| 1777356A1 |
| 1849 |
| 2191-P169077 |
| 51849 |
| BT8308MPG |
| DONP169077 |
| FIL1849 |
| HF6707 |
| HF6707FLG |
| HF740 |
| LFH499 |
