Hydraulic Hose, ID: 1-1/2 in, MegaCrimp
#GAT80048
Product Overview
Recommended for High-Pressure Hydraulic Oil Lines. Exceeds SAE 100R16, SAE 100R2, ISO 11237 2SC R16 & ISO 1436 2SN R2 Requirements & Performance Requirements of EN 857 2SC & EN 853 2SN.
Features & Benefits
- M2T Hose Has Smaller Exterior Dimensions & Significantly Tighter Bend Radius. Meets Flame Resistance Acceptance Designation MSHA 2G.
- Temperature Range: -40 Deg F - +212 Deg F (-40 Deg C - +100 Deg C). Recommended Couplings: GlobalSpiral (Sizes 6 - 16), GlobalSpiral Plus, MegaCrimp & Stainless Steel B (Sizes 4 - 16).
Specifications
| Couleur | Black |
| Recommandation d'accouplement | GlobalSpiral Plus |
| Matériau du couvercle | Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline |
| Type de housse | Type C2 - Flame, Oil, Abrasion & Weather Resistant |
| Dash Size | 24 |
| Description industrielle | 24M2TX25FT |
| Diam. intérieur 1 (po) | 1-1/2 po (3,81 cm) |
| Longueur | 385 ft (117,34 m) |
| Pression maximale | 2000 psi (137.89 bar) |
| Pression minimale d'éclatement (PSI) | 8000 psi (551.57 bar) |
| Diamètre extérieur | 2 in (5.08 cm) |
| Type de produit | M2T MegaFlex 2-Wire Braid Hose - SAE 100R16 |
| Radius | 10 in (25.4 cm) |
| Reinforcement | Two Braids; High-Tensile Steel Wire |
| Standard | SAE 100R16 |
| Temperature Range | -40°F @ 212°F (-40°C @ 100°C) |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Type | Haute pression |
Interchanges & Equivalent parts:
| 80048 |
| 24M2TX25FT |
| SR2SN24 |
| XR16SC24 |
| 04029972 |
| 46574610 |
