Hydraulic Hose, Le: 25 pi, ID: 1 in
#GAT70296
Specifications
| Color | Black |
| Coupling Recommendation | GL, Clamp over Beaded Nipple |
| Cover Material | Chloroprene - Type A |
| Cover Type | Type A - Corrugated - Flame Resistant |
| Dash Size | 16 |
| End 1 Diameter | 1-13/32 in |
| Industrial Description | MULTI MASTER 16GMV MEGAFLEX 1 IN XCTN |
| Inside Diameter 1 (in) | 1 in |
| Length | 25 ft |
| Maximum Pressure | 300 psi (20.68 bar) |
| Minimum Burst Pressure (PSI) | 1200 psi |
| Outside Diameter | 1-13/32 in |
| Product Type | Multi Master GMV Megaflex Return Line & Suction Hose - SAE 100R4 |
| Radius | 1 in |
| Reinforcement | Synthetic; High Tensile Textile Reinforcement w/ Steel Wire Helix |
| Standard | SAE 100R4 |
| Temperature Range | -40 °F to 275 °F; Do Not Convey Fuels Over 120 °F |
| Tube Description | Black |
| Type | Low Pressure |
Interchanges & Equivalent parts:
| 70296 |
| MULTIMASTER16GMVMEGAFLEX1XCTN |
| 46882284 |
