Landing Gear Set, Inside Mounting, Cushion Shoe, 65000 lb Lift, 10 Holes, 200000 lb Static Load, 17 in Travel/Lift Height, For Jost
#MZR568.1027CF
Product Overview
Landing Gear Set, Inside Mounting, Cushion Shoe, 65000 lb Lift, 10 Holes, 200000 lb Static Load, 17 in Travel/Lift Height, For Jost
Features & Benefits
- 17 in cushFt
- Consists of: (1) 568.1004, (1) 568.1008, (2) 568.1040, (2) M5855, (6) FSW405, (3) ENC10MM, (1) M5860, (1) 568.1039, (1) 568.1027CFG, (1) 568.1027CFN
- Shaft standout (R): 4.75 in
- Cross section (Q): 5.25 x 5.25 in
- C2C side down holes (P): 2.25 in
- C2C top mount holes (O): 7.5 in
- Shoe LXW (M): 10 x 1 in
- Cross shaft (K): 568.1007
- Brace lug: 568.104
- Crank hanger: 568.1008, handle (H): 568.1004, C2E outer leg (G): 25 in, fully retract height (F): 33 in, side load capacity: 32000 lb
Specifications
| Application | Jost |
| Lift Capacity | 65000 lb |
| Mounting Type | Inside |
| Number of Holes | 10 |
| Shoe Type | Cushion |
| Static Load Rating | 200000 lb |
| Travel/Lift Height | 17 in |
| Manufacturer Part Number | 568.1027CF |
| Product Category | Landing Gear Set |
| Weight | 204 lb |
