Light Bar, Yellow, V: 12 & 32
#TRL92696Y
Product Overview
LED, Strobe, 16 Diode, Rectangular Yellow, Black 5 Screw Bracket Mount, Class II, Hardwired, Heat Shrink Tap/Stripped Ends/Ring Terminal, 12V, Kit
Specifications
| Amps | 0.2 amp |
| Color | Yellow |
| Contents | Led Lamp |
| Depth | 1-13/32 in (3.58 cm) |
| Flash Pattern | 5 |
| Height | 3-3/32 in (7.85 cm) |
| Kit (Y/N) | Yes |
| Lamp Type | LED Exterior Lighting, Single Version, 16 Diodes |
| Length | 5-63/64 in (15.19 cm) |
| Lens Material | Polycarbonate |
| Material | Aluminum |
| Mount Type | Screws Mount |
| Number Of Wires | 3 |
| Plug Side One | PL-2 (Stripped End) |
| Plug Side Two | Blade Terminal |
| Product Type | Strobe Lamp |
| Shape | Rectangular |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | LED |
| VMRS Code | 034-004-253 |
| Volt | 12V & 32V |
| Weight | 0.72 lb (0.33 kg) |
| Width | 5-63/64 in (15.19 cm) |
| Wire Gauge | 18 ga |
| Wire Length | 3 in (7.62 cm) |
Interchanges & Equivalent parts:
| 25016 |
| 970103318 |
| 92696Y |
| 841392696Y |
| TL92696Y |
| TLD92696Y |
| M20372YCL |
| M20373YCL |
| 78143 |
| 92575Y |
| 8413-92696Y |
| 92696YTLT |
| LIT92696Y |
| TL 92696Y |
| TL 92696Y |
