Marker Clearance Light, Amber & Yellow, Round
#TRL21002Y
Product Overview
Super 21, Incandescent, Yellow Rectangular, 1 Bulb, Marker Clearance Light, P2, 2 Screw, Reflectorized, Super 21 Plug, Stripped End, 12V, Kit
Features & Benefits
- Available with standard or reflectorized lens
- Suitable for PC requirements on a 45-degree angle with additional reflectors
- Version available for ABS requirements
- Optional gaskets available to improve seal between lamp and body
Specifications
| Amps | 0.33 amp |
| Color | Amber |
| Common Size | 2 in (5.08 cm) |
| Contents | Lamp, Plug |
| Current Major | 0.33 amp |
| Depth | 1-19/64 in (3.3 cm) |
| Diamond Shell (Y/N) | Yes |
| Function | A, P2 |
| Height | 2-1/32 in (5.16 cm) |
| Housing Color | Yellow |
| Kit (Y/N) | Yes |
| Length | 6 in (15.24 cm) |
| Lens Material | Acrylic |
| Mount Type | Side Mount |
| Number Of Wires | 1 |
| Plug Side One | Super 21 Plug |
| Plug Side Two | PL-2 (Stripped End) |
| Reflectorized (Y/N) | Yes |
| Series | 21 Series |
| Shape | Round |
| Standard | FMVSS 108, CMVSS 108, DOT, SAE |
| Technology | Incandescent |
| Type | Marker Clearance Light |
| VMRS Code | 034-004-024 |
| Volt | 12V |
| Width | 6 in (15.24 cm) |
| Wire Gauge | 16 ga |
Interchanges & Equivalent parts:
| 3268 |
| 419227512 |
| 460833 |
| 810457 |
| 841321002Y3 |
| 66910 |
| 712235991 |
| TL21002Y |
| TL21002Y3 |
| HT50603268 |
| TLD21002Y3 |
| M155A |
| 21002Y |
| 21002Y3 |
| 1400AK |
| 1410AK |
| 21002Y1 |
| 21002YP |
| 253-455 |
| 253455 |
| MNC253-455 |
| TRU21002Y |
| LIT21002Y |
| P07044 |
| 155A/156A |
| 21002Y-TL |
| 269804 |
| 3099917 |
| 3477 |
| 55620123 |
| 8413-21002Y |
| GRT46873 |
| TL 21002Y |
| TL 21002Y4 |
| TL 21002Y |
| TLD21002Y |
| 1245A |
| 2102A |
| 46073GR0 |
| 46083GR0 |
| LB046701 |
| LT2150Y |
| PT2100A |
| TKL21002Y |
| 34004144 |
| 46083 |
