MegaCrimp Female JIC 37 Flare Swivel, 16G-12FJX
#GATG25171-1612
Specifications
| Angle | 0 deg |
| Coupling Description | MegaCrimp Female JIC 37 Flare Swivel |
| Cut Off (in) – C | 3-41/64 in |
| Fitting Type | Female |
| Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Industrial Description | 16G-12FJX |
| Inside Diameter | 1 in |
| Length | 5-7/8 in |
| Nut Hex (in) – H2 | 1-17/64 in |
| Seal Type | Mated Angle |
| Seat | Standard |
| Seat Angle (degree) | 37 deg |
| Sleeve Inside Diameter | 1-27/64 in |
| Stem Hex (in.) | 1-27/64 in |
| Swivel | Yes |
| Thread | 1-1/16 in-12 |
| Type | MegaCrimp Female JIC 37 Flare Swivel |
Interchanges & Equivalent parts:
| G25171-1612 |
| 710309375 |
