MegaCrimp Female JIC 37 Flare Swivel, 6G-10FJX
#GATG25170-0610
Product Overview
Gates MegaCrimp Couplings are Designed for use w/ Gates Wire Braid Hydraulic Hose to Create a Robust, Leak-Free Assembly. The Pre-Assembled Coupling is Designed w/ a Patented C Insert Attached to the Ferrule.
Features & Benefits
- Surpassed one million impulse cycles during design testing.
- MegaCrimp couplings set a new standard for hydraulic couplings. The unique "C" insert ensures "weep-free" concentric crimping to keep equipment and the environment clean.
- One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torquing by a strong-armed worker. Gates has engineered a solution – Full-Torque Nut technology now available on Gates MegaCrimp and GlobalSpiral couplings.
- Robust Bite-the-Wire Crimp. Low Profile. Full-Stem Insertion. Full-Length Crimp. Tested to Industry-Leading 600,000 Impulse Cycles.
- Simplifies Inventory Management. Environmentally-Friendly TuffCoat Plating for 345 Percent Better Corrosion Resistance than SAE Standard.
- One MegaCrimp Coupling Size can Accommodate Various 1 and 2 Wire Braid Hydraulic Hoses of Different Constructions & Wall Thicknesses, Simplifying Inventory Requirements, Helping to Reduce Costs & Simplifying Coupling Selection.
Specifications
| Angle | 0 deg |
| Description d'accouplement | MegaCrimp Female JIC 37 Flare Swivel |
| Coupure (po) – C | 1-5/8 po (4,14 cm) |
| Type de raccords | Femelle |
| Hose Recommendation | Peut s'adapter à différents diamètres extérieurs de tuyaux sur des tuyaux hydrauliques tressés à un ou deux fils. |
| Industrial Description | 6G-10FJX |
| Inside Diameter | 3/8 po (0,97 cm) |
| Length | 2-49/64 po (7,04 cm) |
| Nut Hex (in) – H2 | 1-1/16 po (2,69 cm) |
| OEM Part # | G25170-0610 |
| Product Number | 710308165 |
| Seal Type | Mated Angle |
| Seat | Standard |
| Seat Angle (degree) | 37 deg |
| Sleeve Inside Diameter | 45/64 po (1,78 cm) |
| Stem Hex (in.) | 45/64 po (1,78 cm) |
| Swivel | Oui |
| Type | Raccord pivotant évasé JIC 37 femelle MegaCrimp |
Interchanges & Equivalent parts:
| 134000610 |
| 10643106 |
| 13400-0610 |
| 144000610 |
| GYH14400-0610 |
| GYH13400-0610 |
| G251700610 |
| SC638610 |
| 1AA10FJ6 |
| G25170-0610 |
| 710308165 |
