MegaCrimp Female JIC 37 Flare Swivel Coupling, Steel, 1-5/16-12 x 1 in, 90° Bent Tube, 16G-16FJX90S
Product Overview
Gates MegaCrimp Couplings are designed for use with Gates Wire Braid Hydraulic Hose to create a robust, leak-free assembly. The pre-assembled coupling features a patented "C" insert that allows usage with different hose constructions and wall thicknesses, ensuring an even distribution of crimping forces for a concentric, weep-free seal. This innovation simplifies inventory requirements since one size can accommodate various hose outside diameters on both one-wire and two-wire braid hydraulic hoses. MegaCrimp couplings are fully qualified EN-performance couplings, delivering reliable performance and environmental protection.MegaCrimp Coupling, Steel, 1-5/16-12 Connection Size 1, 1 in Connection Size 2, Female JIC 37 deg Flare Swivel Connection Type 1, 90 deg Bent Tube Connection Type 2, 5.73 in Length
Features & Benefits
- Surpassed one million impulse cycles during design testing.
- MegaCrimp couplings set a new standard for hydraulic couplings. The unique "C" insert ensures "weep-free" concentric crimping to keep equipment and the environment clean.
- One of the most common causes of hydraulic leaks is a cracked coupling nut or seat due to over-torquing by a strong-armed worker. Gates has engineered a solution – Full-Torque Nut technology now available on Gates MegaCrimp and GlobalSpiral couplings.
- Robust Bite-the-Wire Crimp. Low Profile. Full-Stem Insertion. Full-Length Crimp. Tested to Industry-Leading 600,000 Impulse Cycles.
- Simplifies Inventory Management. Environmentally-Friendly TuffCoat Plating for 345 Percent Better Corrosion Resistance than SAE Standard.
- One MegaCrimp Coupling Size can Accommodate Various 1 and 2 Wire Braid Hydraulic Hoses of Different Constructions & Wall Thicknesses, Simplifying Inventory Requirements, Helping to Reduce Costs & Simplifying Coupling Selection.
Specifications
| Finish | TuffCoat Plating |
| Length | 5-47/64 in |
| Material | Steel |
| Type | MegaCrimp Female JIC 37 Flare Swivel - 90 deg Bent Tube |
| Connection Size 1 | 1-5/16-12 |
| Connection Size 2 | 1 in |
| Connection Type 1 | Female JIC 37 deg Flare Swivel |
| Connection Type 2 | 90 deg Bent Tube |
| Standards | EN-performance |
| Product Category | MegaCrimp Coupling |
| Weight | 1.43 lb (0.65 kg) |
Interchanges & Equivalent parts:
| 144451616 |
| 20241934 |
| 36425-1616 |
| 364251616 |
| GYHB2-JCFX90S-161 |
| GYH36425-1616 |
| GYH20241934 |
| GYH14445-1616 |
| B2JCFX90S161 |
| B2-JCFX90S-161 |
| 1GA16FJB16 |
| G25179-1616 |
| 710347485 |
