| Attenuation Low Range |
15 dBA |
| Attenuation High Range |
20 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
5-63/64 in (15.2 cm) |
| Body Length |
16-57/64 in (42.91 cm) |
| Inlet Clock Position |
6:00 |
| Inlet Diameter |
2 in (5.08 cm) |
| Length |
16-7/8 in (42.88 cm) |
| Outlet Clock Position |
12:00 |
| Outlet Diameter |
2 in (5.08 cm) |
| Overall Length |
19-13/32 in (49.3 cm) |
| Rated Flow High Range |
512.06 cfm (14.5 m³/min) |
| Rated Flow Low Range |
296.64 cfm (8.4 m³/min) |
| Rated Flow Mid Range |
512.06 cfm (14.5 m³/min)[delete] |
| Length Range |
16 to 17 in |
| Style |
Style 5 |
