| Attenuation Low Range |
12 dBA |
| Attenuation High Range |
18 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
5-63/64 in (15.2 cm) |
| Body Length |
15-63/64 in (40.6 cm) |
| Inlet Diameter |
2 in (5.08 cm) |
| Length |
16 in (40.64 cm) |
| Outlet Diameter |
2 in (5.08 cm) |
| Overall Length |
21 in (53.34 cm) |
| Rated Flow High Range |
391.99 cfm (11.1 m³/min) |
| Rated Flow Low Range |
282.52 cfm (8 m³/min) |
| Rated Flow Mid Range |
391.99 cfm (11.1 m³/min)[delete] |
| Length Range |
15 to 16 in |
| Style |
Style 1 |
