| Attenuation Low Range |
12 dBA |
| Attenuation High Range |
18 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
10 in |
| Body Length |
24-1/64 in |
| Inlet Clock Position |
6:00 |
| Inlet Diameter |
4 in |
| Length |
24 in |
| Outlet Clock Position |
12:00 |
| Outlet Diameter |
4 in |
| Overall Length |
29-11/64 in |
| Rated Flow High Range |
1567.97 cfm |
| Rated Flow Low Range |
1412.59 cfm |
| Length Range |
24 to 25 in |
| Style |
Style 5 |
