| Attenuation Low Range |
19 dBA |
| Attenuation High Range |
25 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
8-1/2 in |
| Body Diameter Max |
11-13/16 in |
| Body Length |
25-63/64 in |
| Inlet Clock Position |
3:00 |
| Inlet Diameter |
3 in |
| Length |
26 in |
| Outlet Clock Position |
3:00 |
| Outlet Diameter |
3 in |
| Overall Length |
33-3/4 in |
| Rated Flow High Range |
826.36 cfm |
| Rated Flow Low Range |
476.75 cfm |
| Length Range |
25 to 26 in |
| Style |
Style 2 |
| Type |
Wrapped |
