| Attenuation Low Range |
12 dBA |
| Attenuation High Range |
18 dBA |
| Back Pressure High-Range (Metric) |
76 mm HG |
| Back Pressure High Range |
2.99 in HG |
| Back Pressure Low Range |
0.98 in HG |
| Back Pressure Mid Range |
2.01 in HG |
| Back Pressure Low-Range (Metric) |
25 mm HG |
| Back Pressure Mid-Range (Metric) |
51 mm HG |
| Body Diameter |
12 in (30.48 cm) |
| Body Length |
25-63/64 in (66 cm) |
| Inlet Clock Position |
6:00 |
| Inlet Diameter |
5 in (12.7 cm) |
| Length |
26 in (66.04 cm) |
| Outlet Clock Position |
12:00 |
| Outlet Diameter |
5 in (12.7 cm) |
| Overall Length |
31-39/64 in (80.29 cm) |
| Rated Flow High Range |
2447.31 cfm (69.3 m³/min) |
| Rated Flow Low Range |
1762.2 cfm (49.9 m³/min) |
| Rated Flow Mid Range |
2447.31 cfm (69.3 m³/min)[delete] |
| Length Range |
25 to 26 in |
| Style |
Style 5 |
